Office Copy Paper Production Line

        Mould Cylinder and Fourdrinier Wire A4 Printing and Writing Paper, Newspaper, Office Copy Paper Production Line, Use Material of Wood Pulp and White Waste Recycle Paper.

  • Shipping Port :

    Qingdao
  • Lead Time :

    4 Months
  • Weight :

    100-1500 Tons
  • Min. order :

    1 Set

        Mould Cylinder and Fourdrinier Wire A4 Printing and Writing Paper, Newspaper, Office Copy Paper Production Line, Use Material of Wood Pulp, Bagasse, and White Waste Recycle Paper.

Office Copy Paper Machine model

Paper Output

Culture Paper With Jumbo Roll

Trimmed Width

1092-4800 mm

Machine Gauge

2100-5900 mm

Grammage

50-120 gsm

Design Speed

120-550 mpm

Working Speed

100-500 mpm

Capacity

8-180 tpd

Drive Position

Right Hand or Left Hand Machine

Overview

        This 3150 fourdrinier wire culture paper machine applies to make writing and printing paper with grammage 50-120gsm. The width on pope reel is 3250mm, working speed is 400m/min, capacity 100 tons per day, calculate at 24 hours. It could design with left-hand or right-hand type based on drive position.

Paper Machine Design

        Design tension for felt is 4KN/m, working tension is 3KN/m.

Mould Cylinder Culture Paper Machine

        Stock Preparation -- Approach System -- Mould Cylinder -- Press Section -- Dryer Section -- Pope Reel -- Air Hood -- Rewinder -- Vacuum System -- Air Compressor -- Steam Condensate System

Fourdrinier Wire Paper Machine

        Stock Preparation -- Approach System -- Headbox -- Fourdrinier Wire -- Press Section -- Dryer Section -- Pope Reel -- Air Hood -- Rewinder -- Vacuum System -- Air Compressor -- Steam Condensate System

        Concentration: 0.2-0.4%

        Paper dryness out of wire part 13—18%, go into dryer cylinder 35—38%, at pope reel 90—92%.

Service and Team Work

        Strict quality control department will conduct complete quality inspection, to make sure frame alignment, rubber roll coating and crown, and all parts are correct and perfect paking to deliver to our customer.

        Before shipping we will assemble and test all parts in the pre-assembly workshop to ensure the alignment and integrity of the equipments, and complete all parts even nuts and bolts.

        We will send engineer to customer paper mill to support on installation and machine test running, also will train the workers on opperation.

        Turn-Key service is our advantage, we have professional design engineer, machnical engineer and production enginners all have rich experience on paper mill.

        We will give you profesional design of production line with good price and low investment.
